MERLIN is a microprocessor-controlled ventilator designed by vets for vets. We have done away with conventional pressurised gas driving mechanisms and use a precisely controlled piston that can accurately deliver volumes in the range 1ml to 800mls.
Merlin can be pressure-cycled, volume cycled or time-cycled and the inspiratory and expiratory times are fully and independently variable without the need to re-adjust after changes in flow rates or volumes. A pressure control allows you to set the maximum allowable pressure during volume cycling or the target pressure during pressure cycling.
A further added feature is the inspiratory assist control that will tune the ventilator to your patient during recovery and so assist weaning from the ventilator. On the front of the unit is a large easily readable display that shows all of your selected parameters. These parameters are continuously updated reflecting every adjustment made.
We believe Merlin is truly innovative in being the first veterinary ventilator to calculate and display the compliance of the patient being ventilated.
Key Features of the Merlin Small Animal Ventilator
Precise, reliable control over all ventilation parameters
Fits into rebreathing and non-rebreathing circuits
Pressure cycled, time cycled or volume cycled IPPV
Patient disconnect and over-pressure alarms
80-character screen and high-definition LEDs give full parameter information:
Inspiratory and expiratory airway pressure
Maximum allowed airway pressure
Purpose-designed stainless steel and silicon valves for precise flow control
Standard 22mm/15mm fittings
Suitable for anaesthesia or ICU
Mains powered with fail-safe operation
1 x IEC Power Lead: UK◊ EU◊ US◊ AU◊ 1 x Operating Manual 1 x Tidal Volume Chart / Flow Rate Chart 1 x “Exhaust gas setup for Merlin Ventilator” document 1 x MERL-0001 Merlin Common Scavenge set (Gas Out) 1 x MERL-0002 Merlin Gas Inlet set 1 x MERL-0003 Merlin Low-dead space set 1 x MERL-0006 Merlin Circle Connection kit 1 x CIRSBC15 Smooth Bore Y-Circuit 15mm x 1.8m 1 x CIRSBC222 Smooth Bore Y-Circuit 22mm x 1.8m 1 x VS0230 22M-22F with one-way valve – to patient 1 x VS0232 22M-22F with one-way valve – from patient
Mode of operation: Microprocessor controlled precision piston
Capacity: 1ml to 40mls in 1ml increments
40mls to 120 mls in 5ml increments
120mls to 800mls in 10ml increments
Flow rates: 0.1 to 3.5L/minute in 0.1L increments
3.5 to 25.0 L/minute in 0.5L increments
Inspiratory/Expiratory times: 0.5 to 9.0 seconds in 0.1second increments
Pressure settings: 1 to 57 cm H2O pressure in 1 cm H2O increments
Inspiratory assist setting: -1 to –10 cm H2O pressure in 1cm H2O increments
Valves: Electrically operated solenoid valves. Stainless steel & silicon construction
LCD Module: Backlit 80-character 4-line display
Alarm mode: Audible – 2kHz buzzer. Visual – Flashing red LED and screen message
Gas connections: Front fixing 22mm O/D, 15mm I/D stainless steel ports.
Power failure mode: All valves open. Manual IPPV can be performed.
Overall dimensions: 45cm x 20cm x 34cm
Construction: Enamelled steel box with feet
Power Supply: 230 Volts AC 50Hz mains only. European and USA versions available
As a mechanical ventilation device, this is definitely a veterinary ventilation innovation! With high-performance turbine drive, R420 ventilator no longer needs driven gas! It’s a good solution to gas consumption problem of traditional ventilators. In addition, its easy-to-use working modes and comprehensive monitoring of animal ventilation state can ensure safe ventilation.
Turbo Drive: Electronically driven by a high-performance turbine, no more driven gas
Precise ventilation:Minimum tidal volume down to 4 mL，more friendly to tiny animals.
Smart preset: Once inputting animal weight, smart respiratory parameters can be called up.
Guard “breathing” safety: Accurate and continuous monitoring of respiratory status, such as airway pressure – time chart, minute volume, EtCO2, and etc.
Multiple alarms: Multiple alarms and clear handling prompts ensure the safety of mechanical ventilation
PEEP function: Help veterinarians solve low SpO2 problems during surgery
Auto system leak test：Graphical guidance for quick start
Remote control of inspiratory hold: During a CT scan of the chest or abdomen, help the animal to hold the inspiration and complete the CT scan
Now incorporates alerts and alarms for ventilation status • Patient disconnect • Over-pressure • Apnoea • Valve disconnect or failure
Measurement of inspiratory time and respiratory rate
Select-and-commit entry to prevent false changes
Easy and intuitive to use
Compact, rugged unit
Internal battery for portable/mobile use
Clear, bright visual display
Designed and manufactured in the UK
Safe, simple, pressurecycled ventilation for small animals
The SAV04 is an enhanced version of the long-standing SAV03 ventilator and uses the same principles of simple, pressure-cycled ventilation.
In the redevelopment of the ventilator, features have been added to improve patient control and to improve ventilation status feedback. For example, there is now an automatic over-pressure alarm that will sound if the target pressure is exceeded by 8cm. There is also an alarm if the patient becomes disconnected from the ventilator, or if no back-pressure is detected during the inspiratory phase.
These alarms are designed to be informative and are accompanied by explanatory text on the main screen. In addition, an audible beep is produced on every successful breath. Both this beep and the alarm beeps can be individually silenced if required. There is a new valve design to accompany the new ventilator and this has two major benefits.
Firstly, the valve can be automatically zeroed on any other SAV04 machine allowing valves to be swapped or replaced easily.
Secondly, a larger orifice in the exit port of the valve means the port can now support larger animals. The 12mm diameter exit orifice will now allow unrestricted expiration in animals up to 40kg.
It must be remembered the principle of operation is still based around a T-piece, so proportionately higher fresh gas flow rates will be required. However, with the advent of oxygen generators, running such a system on 8-10L is feasible for short-term or emergency use. The new display now provides more information to the user. A central rising bar graph shows the pressure in the patient’s airway, enabling quick assessments to be made on system and/or ET tube leaks. Each inspiratory period is now measured and displayed on the screen as is the measured respiratory rate.
The new SAV04 provides a simple, yet safe, way to ventilate your smaller, most vulnerable patients.
1 x EN-AC-FG-C203 Aluminium Flight case 1 x ESA24-09-01 Vetronic Medical Devices Mains Charger 9v 1 x Operating Manual 1 x Quick guide 1 x Information sheet “Using the low dead space kit” 1 x CD with files 1 x VS0031 Extension Tubing Kit 1 x VS0032 Low Dead Space Kit 1 x VS0034 Connection Tubing Kit for SAV04
170mm x 170mm x 95mm
Anodised aluminium case with rubber end protectors
9volt DC, 2amp universal input charger
Rear panel fuse rating:
Domestic animals 10g up to 12kg in weight (up to 40kg with high flow rates)
Anaesthetic apparatus configuration:
T-piece with fresh gas and anaesthetic agent in a non-rebreathing circuit
Mode of operation:
IPPV by outlet occlusion. Pressure-cycled/pressure limited device
Preset trigger range:
1-60 centimetres water pressure
1 centimentres water pressure
Expiratory phase range:
0.1 to 60 seconds
Respiratory rate range:
1 to 120 breaths/minute (depending on inspiratory fresh gas flow rate)
